FTR 90 S

Dimension Over all Length ( OAL) mm 10, 005 Over all Width ( OW) mm 2, 400 Over all Height ( OH) mm 2, 720 Wheel Base ( WB) mm 6, 050 Front Over Hang ( FOH) mm 1, 440 Rear Over Hang ( ROH) mm 2, 515 Cabin to end ( CE ) mm 7, 940 Min. Clearence ( HH) mm 245 Tread Front ( AW) mm 1, 990 Tread Rear ( CW) mm 1, 790 Weight Total Vehicle Mass kg 4, 369 Gross Vehicle Mass ( GVW) kg 14, 000 Engine Engine Model 4HK1-TCS Type Inline Four Cylinder, OHC, Direct Injection Diesel Bore and Stroke mm 115x125 Piston Displacement cc 5, 193 Max. Output PS/ rpm 210/ 2, 600 Max. Torque Kgm/ rpm 65/ 1, 600-2, 600 Transmission Transmission Model MZW6P 1st 6, 615 2nd 4, 095 3rd 2, 358 4th 1, 531 5th 1, 000 6th 0, 722 Rev. 6, 615 Final Gear Ratio 6, 500 Brake Brake Control Air Over Hydraulic Tire Front Tyre 9.00-20-14PR ( Miller) Rear Tyre 9.00-20-14PR ( Miller) Suspension Suspension Front Multileaf Suspension Rear Multileaf Others Fuel Tank Capacity Liter 200 Min. Turning Radius m 10, 3 Max. Gradeability % 37 Max. Speed Km/ h 107 Alternator V-A 24-50 Cab wide-5( with bed space) Frame Dimension 850x254x8 Emisi Regulation Euro-2 * Spesifikasi dapat berubah sesuai dengan perkembangan teknologi
